Containerized Filtration System 216,000 GPD - Palau

Application: Potable Drinking Water for Construction Sites (High TSS, hardness and color removal)

This is model MLF60-A & ACF60-A from our MF-1000 Series.

• Containerized solution
• NSF Epoxy Coated Interior Steel Tanks
• Manway Top Loading Port
• Schedule 80 PVC Face Piping
• Electricall Actuated Butterfly Valves
• Differential Pressure Initiation for Backwash
• PLC Controller with NEMA 4X Enclosure
• Flanged Piping Connection
• Chlorine Analyzer
• UV Sterilizer for Disinfection

[custom-specifications]

Water Challenges: This project is aimed at producing potable drinking water by removing unwanted high TSS, hardness, and color from water. The concern for the removal of these unwanted impurities from water applies for many applications in addition to drinking application. For instance, the type of industry might induce the color of water to alter based on various production processes. This occurs in the construction industry, where the presence of high TSS and turbidity adds color to the water. When there is a great degree of suspended solids in the water, turbidity elevates and contributes to color changes.

[/custom-specifications]
[custom-features]

Applied Solution: The containerized industrial media filtration system is one of the best methods of purifying surface water on the market. With rates up to 216,000 GPD, potable drinking water can be made for construction sites, temporary military camps, and industrial use with ease. To make pollutant-free water available in remote areas, the containerized water treatment systems are considered a suitable solution. In this project, the containerized water filtration system included feed and backwash pumps, twin media filters, twin carbon filters, twin water softener, chemical dosing systems, chlorine analyzer and UV sterilizer. The system was controlled by an advanced PLC. Pure Aqua containerized treatment solution are custom engineered to meet your unique water treatment requirements. Our systems are ruggedly built, designed to provide customers with easy installation and trouble-free operation.

[/custom-features]
[custom-usage]

• Requires little or no maintenance
• Improved water taste and clarity without any chemical

[/custom-usage]
