BWRO System 87,000 GPD - Venezuela

Product Description

Application: Plating Operations

This is model BW-87K-2680-5 from our RO-400 Series.

  • RO-400 series
  • Capacity: 87,000 GPD
  • Multi-media filter
  • Chemical dosing systems
  • High pressure stainless steel pump
  • Microprocessor control panel
  • Stainless multi stage pumps
  • TEFC motor


Water Challenges: Brackish water is an unsuitable water source to rely on for plating operations due to their large amounts of pollutants. Total dissolved solids exist in high degrees within brackish water and produces unwanted effects during plating operations such as greater amounts of chemicals for the machinery and maintenance costs to reduce scaling or even replacement worn-down metals. By utilizing high quality water, the plating industry will require the usage of less chemicals, and minimize operating/maintenance costs. Reverse osmosis provides the water treatment solution needed to convert brackish water into fresh, clean water.



Applied Solution: Pure Aqua manufactured and supplied an Industrial Brackish Water Reverse Osmosis system with pre and post treatment systems, to a major company in Venezuela. The plating industry has continued utilizing our advanced reverse osmosis systems since realizing the great usefulness they provide to improving the quality of water used within operations. This RO system includes a stainless steel multi-stage pump with a TEFC motor, modified to produce 87,000 gallons per day.



  • Minimal civil work and construction
  • Small footprint
  • Plug and play installation
  • High-quality components (Grundfos pumps, DOW Filmtec membranes, Codeline vessels, Pure Aqua microprocessor control panel)
  • High recovery design
  • High rejection membranes
  • Low energy and chemical consumption
