HYDRAsub HSM125-ES Membrane

Quality parts at an exceptional value
Product Description

HYDRAsub HSM125-ES Membrane are designed for MBR operations for the purposes purifying effluent that consists of significant biological problems, resulting from sewage or industrial sources. Hollow fiber diaphragms for bioreactor membrane processes in treating wastewater.

[custom-specifications]

  HYDRAsub® - MBR HSM125-ES





Module
Specifications
Configuration:
Fiber Orientation:
Filtrate Flow:
Membrane Polymer:
Pore Size (nominal):
Number of Elements in Module:
Nominal Membrane Area per Module:
Permeate Connections:
Air Connections:
Guide Pipe Connections:
Typical Module Dry Weight:
Typical Module Wet Weight:
Submerged Membrane
Vertical
Bi-directional
Polyvinylidene Flouride (PVDF)
0.4 μm
40 (25 m² each)
5 (25m²each)
1345 ft2 (125m²) (2)-2” MNPT
(2)-11/2”MNPT
(2)-to fit 2.5” pipes
352 lbs (160 kg)
502 lbs (227 kg)





Operating
Specifications
Maximum Trans Membrane Pressure(Vacuum):
Maximum Backwash Pressure:
Maximum Instantaneous Chlorine Concentration:
Maximum Chlorine Tolerance:
MLSS Range:
Operating Temperature Range:
Feed Water pH Range:
Cleaning pH Range:
Operating Mode:
-6 psig (-0.41 bar)
2 psig (0.14 bar)
5,000 ppma
742,000 ppm-hrsb
8,000-12,000 mg/Lc
41-104°F (5 -40°C)
6.0-8.0
1.0 - 11.0
Outside to Inside


Typical
Process
Conditions
Operating Filtrate Flux:
Peak Operating Flux:
Chemically Enhanced Backwash (CEB) Flux:
CEB Chemicals:
Clean In Place (CIP) Flux:
OCIP Chemicals:

4-20 gfd (7-34 lmh)
30 gfd (51 lmh)
2.4 gfd (4 lmh)
NaOCld
2.4 gfd (4 lmh)
NaOCl or Citric Acidd

[/custom-specifications]

[custom-features]

  • Very high flux
  • CAPEX savings
  • Lower footprint
  • PVDF fiber
  • Reliable and robust product

[/custom-features]

[custom-usage]

  • Effluent (sewage or industrial source)
  • Municipal applications

[/custom-usage]
