Industrial BWRO Unit 57,000 GPD - Philippines

Product Description

Application: Drinking Water for Beverage Company

This is model TW-57K-2480 from our RO-400 Series.

  • Pre & Post Treatments
  • Chlorine Injection System
  • Automatic Multi-Media Filtration System
  • Automatic Activated Carbon
  • Antiscalant Injection
  • Brackish Reverse Osmosis System

The process of reverse osmosis deals with the use of a high pressure pump which applies extreme pressure to the high saline concentrated side of a semi-porous membrane, combatting a natural process called "Osmosis". Naturally, osmosis transports salt through a semi-porous membrane from a region with low saline concentration to a region with high saline concentration. Its goal is to gain an equal quantity of saline concentration on both sides of the membrane. With the use of the high pressure pump, reverse osmosis comes in to direct osmosis to the opposite direction. The pump applies high pressure to the highly concentrated saline side of the membrane, pushing salty water and other impurities across the membrane, only allowing water molecules to flow through. Salt and the impurities are rejected and later thrown into the drain on the concentrate side. In the end, we obtain purified water with 99% less dissolved salts on the permeate side of the membrane.


Water Challenges: Beverage companies require the provision of purified water in order to produce high quality beverage products. Since water is the primary product ingredient of which these beverages are made from, it is absolutely unsafe to take half-measures during the production process. Purified water can only be produced from originally untreated water sources from where it is brought from through treatment solutions. These treatment solutions can range from activated carbon, water filtration to reverse osmosis systems, which is what was used during this application in the Philippines.



Applied Solution: Pure Aqua designed and manufactured a brackish groundwater treatment plant for a major company in the Philippines. This plant was manufactured to meet all the client's requirements, including pre- and post-processing filters and chemical injection pumps. The system is capable of producing 57,000 GPD of clean water from a well water feed up to 5000 ppm. This plant was selected from our RO-400 series. From its initial start-up, the industrial reverse osmosis machine for the Philippines has been working properly with minimal trouble-shooting.



  • Minimal civil work and construction
  • Small footprint
  • Plug and play installation
  • High-quality components (Grundfos pumps, DOW Filmtec membranes, Codeline vessels, Pure Aqua microprocessor control panel)
  • High recovery design
  • High rejection membranes
  • Low energy and chemical consumption
