Large Reverse Osmosis System RO-600

(5 reviews)
Quality Systems at an exceptional value
Product Description

Pure Aqua manufactures large reverse osmosis systems from the RO-600 series which are designed to eliminate high concentrations of contaminants in water. These contaminants range from total dissolved solids (TDS), salt, bacteria, proteins, metals, organic substances, dyes, and constituents that contain a molecular weight higher than 150-250 Daltons.

Pure Aqua's comprehensive line of conventional and completely customizable brackish reverse osmosis systems are also engineered through cutting-edge 3D computer modeling and process design technology for precise and tailor-made solutions.

The parts that make up this large RO system include spiral membrane elements constructed from one or multiple membrane envelopes that are engrossed around a perforated central tube. The permeate flow is sent through layers of membranes into the envelope and makes its way to the central tube where it sits. The membrane layers are displayed in the picture to the right.

While smaller systems are designed for most commercial businesses and other lesser-scale applications, our large reverse osmosis system is produced to perfectly handle manufacturing and healthcare facilities of great proportions. Regardless of what type of system that you might require, a large reverse osmosis system is tailor-made to produce you the cleanest water for consumption or other use.

The Filtration Phases of Large Reverse Osmosis Systems

A large reverse osmosis system generally consists of distinct filtration and carbon constituents. Carbon filters work in conjunction with a large RO system to eradicate chlorine, chloramines, disinfectants, VOCs, and pesticides that enhance the taste and odor of water. Commercial water softeners also help by softening water that prevents membrane fouling. This multi-filtration method ensures an extremely purified solution for the production of highly pure water.

Modern large reverse osmosis systems also incorporate pre-filters to eliminate sand, particulate matter, rust, and turbidity that are capable of causing damage to the membranes. It is crucial that you the steps to safeguard your membranes from these potential threats so they can do their work. RO membranes are very efficient in removing a wide range of salt, dissolved solids, lead, heavy metals, organic & inorganic substances, microorganisms. These membranes take in water forced through the system by a high-pressure pump that drives water flow into the pores of the semi-permeable membranes.

There is a storage tank and other water purification optionals that can be used such as uv sterilizers that kill biological organisms, water deionizer systems used as post-filtration to ensure ultra-pure water.

The Benefits of a Large Reverse Osmosis System

  • Enhanced flavor, smell and appearance
  • Purifying procedure with high quality
  • Takes out contaminants
  • Conductivity/total dissolved solids decrease
  • Brings down hardness in water
  • Reduced price for high value
  • Mitigates alkalinity

Other water treatment systems can minimize contamination and may take significant initiative to operate over time. These units also include additional pollution risks can arise if something fails with that specific system. Your water, however, remains fresher spotless through the use of reverse osmosis.

There are various utilizations that a large reverse osmosis system is suitable to handle in both industrial and commercial industries. Although everybody needs their water to be healthy water supply and nice drinking water, companies require clean water to make the most of their business operations. Food suppliers, health facilities, pharmaceutical companies and industrial cooling towers could all benefit from the reliably clean and fresh water provided by the method of reverse osmosis.

Large RO systems are capable of eliminating other impurities not known by many users such as flouride, arsenic, radium, nitrate, sulfate, potassium, and more. Once these substances are taken out by the membranes, they are discharged and flushed away.

Maintenance is made to be simple and extremely cost-effective. Users are only required to clean and change the RO membranes and filters in use on an occassional basis, including sanitizing the system itself. Our RO-600 large RO system provides a user-friendly option to guarantee pristine water purification.

[custom-specifications]
industrial brackish water reverse osmosis BWRO systems 200000-900000 gpd specifications

Operation Specifications:

  • Max. feed water temperature: 42°C

  • Feed water pressure: 20 to 80 psi

  • Operating pressure: 150 to 250 psi

  • Hydrogen Sulfide must be removed

  • Turbidity should be removed

  • Max. iron content: 0.05 ppm

  • Feed water TDS: 0 to 1,000 or 3,000 or 5,000 ppm

  • Equipment upgrade for TDS over 5,000 ppm

  • Hardness over 1 GPG requires antiscalant dosing

  • pH tolerance range: 3-11

  • Max. Silica Tolerance: 60 ppm @ 60% recovery

  • Operate at higher TDS by lowering recovery

Model Number

Permeate Flow Rate

Quantity of 8" Membranes

Motor Rating at 1,000 ppm

MGPD

M3/D

60Hz (hp)

50Hz (kw)

TW-1.0M-24680

1.00

3,785

144

100

75

TW-1.25M-24780

1.25

4,731

168

125

95

TW-1.5M-30780

1.50

5,677

210

150

120

TW-2.0M-37780

2.00

7,570

259

250

200

For more information, please view/download our "Data Sheet"

Note: If the feed water TDS exceeds 1,000 ppm, the system model number changes to BW-XM-XXXXX, and a suffi x is added to the end of the model number: “-3” is addedif the TDS is 3,000 ppm or less, and “-5” is added if the TDS is 5,000 ppm or less.
Example: Required system to produce 1.5 MGPD with a feed water TDS of 5,000 ppm, the corresponding model number is: “BW-1.5M-30780-5”.

[/custom-specifications]

[custom-features]
industrial brackish water reverse osmosis BWRO systems 200000-900000 gpd features

Standard Features:

Available Options:

  • Powder coated carbon steel frame

  • 8” TFC spiral wound membranes

  • Stainless steel multi-stage pump with TEFC motor

  • FRP membrane housings

  • 5 micron cartridge prefilter

  • 460V/3ph/60Hz power requirement

  • PLC based control panel

  • Programmable time delay and set points

  • Motor starter

  • NEMA 12 enclosure

  • Low pressure switch

  • High pressure switch

  • Liquid filled pressure gauges

  • Permeate conductivity monitor

  • Permeate & concentrate flow meters

  • Remote monitoring

  • Feed water conductivity monitor

  • Membrane cleaning skid

  • Automatic hourly flush

  • Feed/Permeate blending

  • Export crating

  • 380-415V/3ph/50 or 60Hz

  • Product tank level switch

  • pH & ORP controller with sensor

  • Water and hour meters

  • Chemical dosing systems

  • Media prefiltration systems

  • Ozonation and UV sterilization

  • Water softeners

  • Post deionization polishers

  • Containerized RO systems

[/custom-features]

[custom-usage]

The RO-600 series is most suitable for operating among these applications:

  • EDI Pre-treatment

  • Food and Beverage

  • Beverage Production and Bottled Water

  • Safe Drinking Water

  • Rinse Water

  • Spot Free Product Rinse

  • Electronics

  • Power Plants

  • Boiler Feed Water

  • Pharmaceutical

  • Mining Industry

  • Chemical Blending

  • Ice Manufacturing

  • Plating Operations

  • Cooling Towers

  • Laboratory Water Purification System

  • Ion Exchange Pre-treatment

  • Metal Finishing

[/custom-usage]
[custom-documents]
[custom-360-view]

Here at Pure Aqua, Inc., we engineer and build all of our water treatment systems in-house.

Our turn-key water treatment systems are all pre-engineered using the latest CAD technology available.

This enables our teams to build and deliver treatment systems to our customers with quick turnaround times.

Many of our customers require custom engineered systems. These are typically built around similar core systems and thus allowing for improved turnaround times, even for one-off designs.


[/custom-360-view]
