Myron L 750II CONDUCTIVITY/TDS

Myron L 750II CONDUCTIVITY/TDS
Product Description

The unique circuitry of the Myron L 750II CONDUCTIVITY/TDS monitor ensurs users with high precision and dependable measurement information, while providing drift-free operational performance that incorporates field-proven technology, mechanized DC offset recompense, and a detailed drive voltage.

[custom-specifications]

Myron L 750II CONDUCTIVITY/TDS Specifications:
Ranges 34 ranges from 0-1 ppm/µS (µM) to 0-200 ppt/mS (mM) See Price List for further details
Display Analog Models: 2.5 in./63 mm
Digital Models: .5 in./13 mm 3½ Digit LCD
Optional: 3½ or 4½ Digit Backlit
Accuracy Analog Models: ± 2% of full scale
Digital Models: ± 1% of full scale
Sensitivity 0.05% of full scale
Stability 0.05% of full scale
Repeatability 0.1% of full scale
Calibration Check Built-in
Recorder Output 0-10 VDC @ 5 mA max. (linear); standard all models
Sensor Inputs 1 (3 input option available)



Control Function		 Single Alarm/controller fully adjustable 0-100% of full scale
Hysteresis: Adjustable from 0.3-3% of full scale
Indicators: Above (red) and below (green) setpoint LEDs
(reversible)
Contact Rating: SPDT 10 amp @ 250 VAC, 30 VDC. Relay
operates decreasing or increasing reading (selectable)
Second Alarm/controller, with above specifications - optional
Solid State Output Powered; 24 VDC unregulated 30 mA max
Power 115/230 VAC, 50/60 Hz, ±15% (user selectable)
24 VAC optional
Maximum Power Consumption @ 115V: 100 milliamps
Dimensions 152 H x 122 W x 96 D mm / 6 H x 4.8 W x 3.8 D in.
Construction Fully gasketed heavy-duty ABS case; water resistant and
corrosion proof IP65/NEMA 4X rated
Ambient Temp Range 0 - 60°C / 32 - 140°F
Weight 0,9 kg/2 lbs.

[/custom-specifications]

[custom-features]
  • Built-in electronic calibration
  • Single setpoint/alarm
  • Adjustable setpoint hysteresis
  • Solid State 24 VDC Output
  • 10 amp relay operates on choice of increasing or decreasing reading
  • LEDs show “above/below” Alarm/ control status
  • Push-to-test setpoint check
  • Internal setpoint discourages unauthorized adjustment
  • Selectable 115/230 VAC
  • Unique, easily installed sensor
[/custom-features]
[custom-usage]
  • Reverse Osmosis
  • Process Control
  • Seawater Desalination
  • Waste Treatment
  • Food Processing
  • Plating
  • Power Plants
  • Laboratories
  • Printing
  • Aquaculture
  • Agriculture
  • Environmental Studies
  • Medical
  • Boilers (250 psi @ 205°C)
  • Cooling Towers

[/custom-usage]
[custom-documents]
Myron L 750II CONDUCTIVITY/TDS Data Sheet
[/custom-documents]
Models
Features
Applications
Docs
Videos
360 View
Reviews
(1 review) Write a Review
  • 5
    Fast delivery

    Posted by Carl A. on Jun 18th 2019

    VERY FAST DELIVERY & QUALITY PERFORMANCE. THANKS
