Application: Boiler Feed
This is model TW-12K-840 from our RO-200 Series.
- Advanced microprocessor control panel
- RO system (RO-200 series)
- Flow Rate: 12,000 GPD
- Feed water TDS: 1,000 ppm
The process of reverse osmosis deals with the use of a high pressure pump which applies extreme pressure to the high saline concentrated side of a semi-porous membrane, combatting a natural process called "Osmosis". Naturally, osmosis transports salt through a semi-porous membrane from a region with low saline concentration to a region with high saline concentration. Its goal is to gain an equal quantity of saline concentration on both sides of the membrane. With the use of the high pressure pump, reverse osmosis comes in to direct osmosis to the opposite direction. The pump applies high pressure to the highly concentrated saline side of the membrane, pushing salty water and other impurities across the membrane, only allowing water molecules to flow through. Salt and the impurities are rejected and later thrown into the drain on the concentrate side. In the end, we obtain purified water with 99% less dissolved salts on the permeate side of the membrane.
Water Challenges: In the boiler industry, high quality water is a strict requirement for assurance of an efficient steam generation process. Water that contains little-to-no presence of contaminants greatly reduce the amount of chemicals needed because blowdown frequency reduction. This occurrence is important since blowdown frequency reduction leads to lower fuel costs. In addition, heat transfer efficiency is sharply increased as the lack of contaminants present will mean less potential for scale buildup, which effectively reduces fouling. Corrosion is a minimal throughout boilers when there is a high purity of water used as well. For this reason, reverse osmosis is incorporated in boiler feed operations to maximize the productivity of the overall process.
Applied Solution: A commercial Reverse Osmosis System with advanced microprocessor control panel was manufactured and supplied to a major company in IL, USA.From its initial start-up, the machine has been working properly with minimal trouble-shooting. A quality reverse osmosis machine is designed to deliver high quality service by removing massive amounts of salt and other impurities from wells, lakes, rivers, and the ocean through a process called 'reverse osmosis".
Low operating cost, compact size, reduced footprint, and high quality production of freshwater.
